Shrink Packing Machine
TWT SP08 shrink packing machine is advanced shrink PE packing machine, widely used in outside shrink package for medicine, cosmetics, stationery, plastic products, knitted cotton products, arts & crafts, floor, metal wire mesh, household electric applicances and pallet packaging of beverage.
Convey Speed : 0 -10m /min
Max.Power : 28 Kw
Powe r : Three Phase 380V, 50HZ
Outside Size : 4.56×1.46× 1.96 m
Weight : 2600 Kg
| |
TWT SPM Series:
Characteristics:
1, This machine enjoys one-time finishing of conveying, heating, holding and colding.
2, With stainless steel electric heating pipe with radiator slip, high radiation effect.
3, Inside stainless steel mirror radiation plate, long-term effective heating radiation.
4, Temperature visible regulator, precise temperature, instant control.
5, Big power heat wind circle fans, good hot wind circulation effect.
6, Smooth speed precision 1%, a strong loading capacity. |
| |
 |
| |
Spefication |
TWT SPM-43 |
AH-PES-44 |
AH-PES-63 |
Power |
Three Phase 380V, 50HZ |
Convey Speed |
0 -10m /min |
Heating Channel( widthxheight) |
450x 300mm |
450x 450mm |
600x 300mm |
Max.Power |
15kw |
16kw |
17kw |
Outside Size |
2600x660x 1400mm |
2600x660x 1550mm |
2600x810x 1400mm |
|
| |
|
